| Technical Data | ||
|---|---|---|
| Brand | Stego | |
| Item | Electronic hygrotherm | |
| IP Rating | IP20 | |
| Setpoint Type | Adjustable | |
| Contact 1 | 32 to 140 deg F | |
| Contact 2 | 50% to 90% relative humidity | |
| Switching Differential | 3.6 deg F/4% RH | |
| Switching Tolerance | +/-1.8 deg F temperature, +/-1% RH at 77 deg F and 50% RH | |
| Reaction Time | 5 seconds | |
| Operating Voltage | 100-240 VAC | |
| Maximum Switching Capacity | 10A resistive / 1.6A inductive | |
| Connection | 5-pole terminal for 14 AWG max solid or stranded wire | |
| Indicating Type | LED indication | |
| Mounting | 35mm DIN rail | |
| Application | For electrical enclosure climate control | |
