| Technical Data | ||
|---|---|---|
| Brand | Stego | |
| Airflow Direction | Exhaust | |
| Item | Fan | |
| Mounting | Top | |
| With Air Flaps | No | |
| Filter Media | G3 (coarse) filter mat | |
| Free Airflow | 338 CFM | |
| Operating Voltage | 115 VAC | |
| Frequency | 50/60 Hz | |
| Power Consumption | 85W | |
| Electrical Connection | 3-pole clamp for AWG 14 wire, 7.1 in-lb maximum clamping torque | |
| Operating Temperature | -13 to 158 deg F | |
| Average Noise Level | 67 dBA | |
| NEMA Rating | 3R | |
| Application | Safe for outdoor use | |
| IP Rating | IP32 | |
| Enclosure Cutout | 9.69 x 9.69in | |
| Color | RAL 7035 light gray | |
| Includes | Mounting hardware | |
| Additional Information | Purchase intake grille separately. Refer to technical specifications for 50Hz performance data | |
