| Technical Data | ||
|---|---|---|
| Brand | Eaton | |
| Item | Photoelectric sensor | |
| Shape | Rectangular | |
| Housing Size | 73 x 48.5 x 46mm | |
| Thread mounting base size | 30mm | |
| IP Rating | IP67 | |
| Application | Long range and standard duty | |
| Housing Material | Plastic | |
| Sensing Method | Through-beam emitter | |
| Operating Voltage | 12-240 VDC/24-240 VAC | |
| Number of Wires | 4 | |
| Sensing Distance | 500ft | |
| Sensitivity | Potentiometer | |
| Light Emission | Infrared | |
| Connection | 4-pin AC micro connector and 1/2in - 20UNF thread | |
| Includes | Mounting hardware | |
| Additional Information | Purchase cable separately | |
