| Technical Data | ||
|---|---|---|
| Brand | Gates | |
| Item | Hose assembly | |
| Series | MXT | |
| Working Fluid | Petroleum based hydraulic fluid | |
| Material | Synthetic rubber | |
| Reinforcement | Braided steel wire | |
| Color | Black | |
| Inside Diameter | 3/4in | |
| Outside Diameter | 1.08in | |
| Connection | (2) -12 female straight JIC 37 deg fittings | |
| Minimum Bend Radius | 4.8in | |
| Working Length | 10ft working length | |
| Operating Pressure | 3125 psi | |
| Operating Temperature | -40 to +212 deg F | |
| Duty Rating | 600,000 cycles | |
