| Technical Data | ||
|---|---|---|
| Brand | WERMA | |
| Item | Audible-visual signal beacon | |
| Series | EvoSIGNAL Mini TwinFLASH | |
| Bulb Type | LED | |
| Operator Size | 62mm | |
| Operator Color | Clear | |
| Light Color(s) | Clear/white | |
| Light Function | Double flash (ON 30ms, Off 160ms, ON 30ms, Off 740ms, 1 Hz flash frequency) or EVS (Enhanced Visibility System) flashing (random flashing) | |
| Housing Material | Polycarbonate | |
| Material | ABS/polycarbonate | |
| Loudness Decibel | 95 dB at 1m | |
| Tone Frequency | 4 kHz | |
| Tone Type | Continuous/pulse | |
| Touch to Acknowledge | No | |
| Number of Alarms | 2 | |
| Voltage Rating | 24 VAC/VDC | |
| Mounting | Modular | |
| IP Rating | IP66 | |
| Connection | Push-in terminal | |
| Requires | Mounting adapter | |
