| Technical Data | ||
|---|---|---|
| Brand | WEG Electric | |
| Item | Motor | |
| Series | S | |
| Efficiency Group | Standard efficiency | |
| Efficiency | 72 | |
| Voltage Type | AC | |
| Motor Type | Induction | |
| Motor Application | General purpose, inverter rated and brake | |
| Horsepower Rating | 1/2hp | |
| Number of Phases | 3 | |
| Voltage Rating | 208-230/460 VAC | |
| Synchronous Speed | 1800rpm | |
| Nameplate RPM | 1730rpm | |
| Overload Type | None | |
| Enclosure Type | TEFC | |
| Shaft Type | Round with square key | |
| Shaft Diameter | 5/8in | |
| Shaft Material | 1045 carbon steel | |
| Motor Frame | NEMA 56 | |
| Frame Material | Rolled steel | |
| Electrically Reversible | Yes | |
| Insulation Class | Class F | |
| IP Rating | IP55 | |
| Constant Torque Rating | 10:1 | |
| Variable Torque Rating | 1000:1 | |
| Service Factor | 1.15 | |
| Integrated Brake | Yes | |
| Brake Voltage Rating | 208-230/460 VAC | |
| Brake Torque Rating | 2.95 lb-ft | |
| Brake IP Rating | IP23 | |
| Manual Brake Release | Yes | |
| Junction Box Orientation | F1 | |
| Mounting | Rigid base | |
| Mounting Orientation | Horizontal | |
| Includes | Stearns 104816100KQ brake assembly | |
