| Technical Data | ||
|---|---|---|
| Brand | Murrelektronik | |
| Item | IO-Link hub | |
| Number of Analog Input Channels | Up to (4) | |
| Analog I/O Port Type(s) | (4) 5-pin M12 A-coded | |
| Analog Input Signal Type | Current/voltage | |
| Number of Isolated Analog Input Commons | 1 | |
| Number of Points per Analog Input Common | 1 | |
| Input Resolution | 24-bit | |
| Input Current Signal Range | 0-20 mA and 4-20 mA | |
| Input Voltage Signal Range | +/- 5 VDC, 0-5 VDC, +/- 10 VDC and 0-10 VDC | |
| IO-Link Version | IO-Link v1.1.2 (compatible with v1.1.3) | |
| Communication Port and Connection Type(s) |
| |
| Port Protocol(s) |
| |
| Port Speed(s) |
| |
| Indicator | LED | |
| IP Rating | IP65, IP67 and IP68 | |
| Temperature Rating | -25 to 70 deg C | |
| Includes | Marking tags | |
| Requires | IO-Link master | |
| Programming Software | Murrelektronik IO-Link Device Tool v4.0 or later | |
