| Technical Data | ||
|---|---|---|
| Brand | WERMA | |
| Item | Signal tower | |
| Bulb Type | LED | |
| Series | ESIGN | |
| Number of Pre-Assembled Tiers | 15 | |
| Diameter | 72mm | |
| Light Color(s) | Custom programmable colors | |
| Light Function | Selectable permanent, blinking, flashing, double flash, triple flash or rotating | |
| Number of Alarms | 10 | |
| Loudness Decibel | 105 dB at 1m | |
| Tone Frequency | 900 Hz to 3.6 kHz | |
| Tone Type | (10) selectable | |
| Communication Port and Connection Type(s) |
| |
| Voltage Rating | 24 VDC | |
| Lens Type | Clear | |
| Body Length | 372mm | |
| Body Color | Black | |
| Body Material | Polycarbonate | |
| Tower Viewing Angle | 360 degree | |
| Connector Type | 8-pin M12 A-coded | |
| Mounting | Base or tube | |
| IP Rating | IP66 and IP69K | |
