| Technical Data | ||
|---|---|---|
| Brand | Minerallac | |
| Item | Clamp | |
| Clamp Type | Beam | |
| Attachment Type | Screw-on | |
| Mounting Holes | 5/16-18 UNC bottom and 5/16-18 UNC back | |
| Load Rating | 525 lbs | |
| Material | Malleable iron | |
| Finish | Zinc plated | |
| Maximum Flange Thickness | 3/4in | |
| Set Screw Size | 3/8in-16 UNC | |
| Tightening Torque | 60 in-lb | |
| Quantity per Pack | 6 | |
| For Use With | Flanges up to 3/4in and 5/16-18 threaded rod | |
