| Technical Data | ||
|---|---|---|
| Brand | Minerallac | |
| Item | Clamp | |
| Clamp Type | Beam | |
| Attachment Type | Screw-on | |
| Mounting Holes | 1/2-13 UNC bottom and 1/2-13 UNC back | |
| Load Rating | 900 lbs | |
| Material | Malleable iron | |
| Finish | Zinc plated | |
| Maximum Flange Thickness | 7/8in | |
| Set Screw Size | 5/8in-11 UNC | |
| Tightening Torque | 250 in-lb | |
| Quantity per Pack | 6 | |
| For Use With | Flanges up to 7/8in and 1/2-13 threaded rod | |
