| Technical Data | ||
|---|---|---|
| Brand | WAGO | |
| Item | Circuit protector | |
| Circuit Breaker Type | Compact | |
| Circuit Type | Supplementary | |
| Current-Limiting | Yes | |
| Amperage Rating | 3.8A | |
| Input voltage range | 18-30 VDC | |
| Output Voltage Range | 18-30 VDC | |
| Channels | 4 independent | |
| Trip Type | Electronic | |
| Reset | Remote or local | |
| NEC Class 2 | Yes | |
| HACR Rated | No | |
| Reverse Feed Capable | No | |
| Mounting | 35mm DIN rail | |
| Connection | Push-in cage clamp | |
