| Technical Data | ||
|---|---|---|
| Brand | Ergoswiss | |
| Item | Spindle lifting column | |
| Series | SQ | |
| Stroke | 300mm | |
| Load Rating | 330 lbs/150 kg | |
| Lifting Speed | 9mm/sec | |
| Average Noise Level | <60 dBA | |
| Voltage Rating | 24 VAC | |
| IP Rating | IP20 | |
| Slot Size | 8 | |
| Operating Temperature | 50 to 104 deg F | |
| For Use With | 40 x 40mm and 1.5 x 1.5in profile T-slotted rails | |
| Includes | (1) 6.5ft/2m power cable | |
| Requires | Ergoswiss 124.43801-PP000001 control box | |
