| Technical Data | ||
|---|---|---|
| Brand | STAHL | |
| Series | ISpac | |
| Item | Isolator | |
| Isolator Type | Frequency transmitter | |
| Intrinsically Safe | Yes | |
| Input | (1) 0.001 Hz to 20 kHz | |
| Output | (1) 0-20 mA or 4-20 mA and (2) N.O./N.C. configurable | |
| Maximum Voltage | 10.5 VDC | |
| Maximum Current | 23.4 mA | |
| Maximum Power | 61.4 mW | |
| Operating Voltage | 24 VDC | |
| Housing Material | Polyamide | |
| Mounting | 35mm DIN rail | |
| Connection | Screw terminals | |
| Application | Hazardous location rated | |
| Manufacturer Part Number | 9146/10-11-12s | |
