| Technical Data | ||
|---|---|---|
| Brand | STAHL | |
| Series | ISpac | |
| Item | Isolator | |
| Isolator Type | Temperature input | |
| Intrinsically Safe | Yes | |
| Input | RTD or thermocouple | |
| Output | 0-20 mA and 4-20 mA | |
| Maximum Voltage | 6.5 VDC | |
| Maximum Current | 19.7 mA | |
| Maximum Power | 32 mW | |
| Operating Voltage | 24 VDC | |
| Housing Material | Polyamide | |
| Mounting | 35mm DIN rail | |
| Connection | Screw terminals | |
| Application | Hazardous location rated | |
| Requires | External reference junction (part number 9191-VS-05) for thermocouple applications | |
| Manufacturer Part Number | 9182/10-51-11s | |
