| Technical Data | ||
|---|---|---|
| Brand | LS Electric | |
| Item | Gearbox | |
| Application | High-precision | |
| Gearbox Type | Planetary | |
| Gear Ratio | 10:1 | |
| Output Configuration | Inline | |
| Gearbox Output Shaft Diameter | 40mm | |
| Nominal Output Torque | Nominal output torque 500 N-m (4426 lb-in) | |
| Number of Stages | 1 | |
| Frame | 142mm | |
| For Use With | APM-FF series 3.5 kW and 5.5 kW motors | |
| Includes | Input adapter bushing, motor mounting hardware and output shaft key | |
| Manufacturer Part Number | MSS1421A-010KS-E3110103C35 | |
