| Technical Data | ||
|---|---|---|
| Brand | AcuAMP | |
| Item | Current transducer/switch | |
| Voltage Type | AC | |
| Number of Phases | 1 | |
| Body Type | Fixed core | |
| Sensing Range | 0-200A | |
| True RMS | No | |
| Trip Point | 4-200A adjustable | |
| Trip Point Adjustment | Single-turn potentiometer with trip point display | |
| Output | 4-20 mA or solid state switch, N.O. | |
| Output Rating | 1A @ 240 VAC | |
| Operating Voltage | 24 VAC/VDC | |
| Mounting | Panel or optional 35mm DIN rail | |
| Electrical Connection | Screw terminals | |
| UL Rating | UL 508 listed | |
