| Technical Data | ||
|---|---|---|
| Brand | Eaton | |
| Series | Freedom | |
| Item | Motor starter | |
| Starter Type | Non-combination | |
| Coil Voltage | 120 VAC (60Hz)/110 VAC (50Hz) | |
| Amperage Rating | 12A | |
| Voltage Rating | 600 VAC | |
| Horsepower Rating | 7-1/2hp | |
| Overload Type | Bi-metallic | |
| Number of Poles | 3 | |
| Power Poles | (3) N.O. | |
| Auxiliary Contacts | (1) N.O. | |
| Trip Class | Based on heaters used | |
| Phase Loss Sensitive | Yes | |
| Ground Fault Protection | No | |
| SCCR Rating | 5kA SCCR | |
| UL Rating | UL 508 rated | |
| Frame | 45mm | |
| Additional Information | Heater packs sold separately | |
