AVS-5241

AVS-5241

NITRA pilot valve, 5-port (4-way), 2-position, single air pilot spring return, (1) 1/8in female NPT inlet(s), (2) 1/8in female NPT outlet(s), (2) 1/8in female NPT exhaust(s), (1) 1/8in female NPT pilot(s), Cv=0.78.

$37.50
/
Technical Data
BrandNITRA
ItemValve
Working FluidPneumatic
Valve TypePilot directional control
Port Quantity5-port (4-way)
Number Of Positions2
ActionSingle air pilot spring return
MountingOptional manifold
Inlet Port(1) 1/8in female NPT
Outlet Port(2) 1/8in female NPT
Exhaust Port(2) 1/8in female NPT
Pilot Port(1) 1/8in female NPT
StackableNo
Flow Coefficient0.78
Downloads
Technical Specifications Manual Insert Software Firmware Helpfile 2d Drawing 3d Model
