| Technical Data | ||
|---|---|---|
| Brand | Marathon | |
| Item | Motor | |
| Efficiency Group | Standard efficiency | |
| Efficiency | 62 | |
| Voltage Type | AC | |
| Motor Type | Induction | |
| Motor Application | Fan and blower | |
| Horsepower Rating | 1/3hp | |
| Number of Phases | 1 | |
| Voltage Rating | 115/208-230 VAC | |
| Synchronous Speed | 1800rpm | |
| Nameplate RPM | 1725rpm | |
| Overload Type | Automatic | |
| Enclosure Type | ODP | |
| Shaft Type | Round with square key | |
| Shaft Diameter | 5/8in | |
| Shaft Material | 1117 steel | |
| Motor Frame | NEMA 56 | |
| Frame Material | Rolled steel | |
| Electrically Reversible | Yes | |
| Insulation Class | Class B | |
| IP Rating | IP22 | |
| Service Factor | 1.35 | |
| Integrated Brake | No | |
| Junction Box Orientation | F1 | |
| Mounting | Resilient base | |
| Mounting Orientation | Any | |
| Manufacturer Part Number | 5KC36LN1X | |
