| Technical Data | ||
|---|---|---|
| Brand | Metrol | |
| Item | Limit switch | |
| Application | Low contact force | |
| Switch Type | Precision touch | |
| Diameter | 10mm | |
| Barrel Type | Threaded | |
| Length | 30mm | |
| Head Type | 1.5mm radius | |
| Actuator Type | 2mm plunger | |
| Contact Force | 0.1N | |
| Switching Output | NPN, N.O. | |
| Cable Length | 9.8ft/3m | |
| Connection | Pigtail | |
| Conductor Size | 30 AWG | |
| Stroke | 2mm | |
| Repeatability | 0.01mm | |
| Thread Pitch | 0.5mm | |
| Material | Stainless steel | |
| IP Rating | IP40 | |
| Operating Temperature | 0 to 60 deg C | |
| Includes | Mounting hardware | |
