| Technical Data | ||
|---|---|---|
| Brand | DirectLOGIC | |
| Item | PLC | |
| Series | DL05 | |
| Total Memory | 6k words | |
| Ladder Memory | 2k words | |
| User Data Memory | 4k words | |
| Programming Language | Ladder | |
| Programming Software | DirectSOFT programming software v4.0 or later | |
| Communication Port and Connection Type(s) |
| |
| Port Protocol(s) |
| |
| Port Speed(s) |
| |
| Real Time Clock/Calendar | No | |
| Retentive Memory | No | |
| Battery Backup | No | |
| Maximum Expansion Modules Allowed | 1 | |
| External Power Requirement | 120-240 VAC | |
| Number of Discrete Input Points | 8 | |
| Nominal Input Voltage | 120 VAC | |
| Voltage Type | AC | |
| Number of Isolated Discrete Input Commons | 2 | |
| Number of Points per Discrete Input Common | 4 | |
| Number of Discrete Output Points | 6 | |
| Nominal Output Voltage | 12-24 VDC/12-240 VAC | |
| Discrete Output Type | Relay | |
| Relay Configuration | (6) Form A (SPST) relays | |
| Load Current | 2A/point | |
| Number of Isolated Discrete Output Commons | 2 | |
| Number of Points per Discrete Output Common | 3 | |
| Maximum Number of PID Loops | 4 | |
