| Technical Data | ||
|---|---|---|
| Brand | ProSense | |
| Item | Proximity sensor | |
| Sensor Type | Inductive | |
| Application | Standard duty and long range | |
| Shape | Rectangular | |
| Housing Size | 80 x 40 x 105mm body | |
| Housing Material | Polyphenylene ether | |
| Sensing Method | Extended sensing | |
| Adjustable | Yes | |
| Number of Wires | 3 | |
| Switching Output | PNP | |
| Operation Mode | N.O./N.C. selectable output | |
| Sensing Distance | 20-60mm | |
| Mounting Type | Non-flush | |
| IO-Link Compatible | No | |
| Switching Frequency | 100 Hz | |
| Operating Voltage | 10-36 VDC | |
| Operating Temperature | -25 to 80 deg C | |
| Weld Field Immune | No | |
| Chip Immune | No | |
| IP Rating | IP65 | |
| Connection | Terminal chamber | |
| Conductor Size | 2.50 mm2 (14 AWG) | |
