| Technical Data | ||
|---|---|---|
| Brand | C-more Micro | |
| Item | HMI | |
| Series | EA3 | |
| Touch Screen | Yes | |
| Display Size | 3in | |
| Viewable Size | 3.1in | |
| Display Type | Monochrome STN LCD | |
| Widescreen | No | |
| Display Maximum Colors | 12-color monochrome | |
| Display Resolution | 128 x 64 pixel | |
| Touch Panel Type | Resistive single-touch | |
| Brightness | 150nits | |
| Display Orientation | Landscape | |
| Backlight Type | LED | |
| External Power Requirement | 5 VDC, 12-24 VDC | |
| Housing Rating | NEMA 4/4X | |
| Environmental Requirements | Indoor use only | |
| IP Rating | IP65 | |
| Mounting | Panel | |
| Communication Port and Connection Type(s) |
| |
| Port Protocol(s) |
| |
| Port Speed(s) |
| |
| Programming Software | EA-MG-PGMSW programming software v4.2 or later | |
| Includes | Mounting hardware and gasket | |
| Additional Information | Selectable LED backlight for longer lifetime; red, green, amber, yellow, lime, pink1, pink2, pink3, emerald1, emerald2, emerald3 and white. Power is supplied to the panel through a 12-24 VDC power supply or it can receive power from the serial communications port of most AutomationDirect PLCs or through the USB port when connected to a PC for programming | |
