| Technical Data | ||
|---|---|---|
| Brand | DirectLOGIC | |
| Item | Input module | |
| I/O Module Type | Analog | |
| Series | DL405 | |
| Number Of Input Channels | 8 | |
| Input Signal Type(s) | Current/voltage | |
| Analog Input Type | Sinking | |
| Isolated Channels | No | |
| Number of Non-Isolated Input Commons | 1 | |
| Input Resolution | 12-bit | |
| Input Current Signal Range | 0-20 mA and 4-20 mA | |
| Input Voltage Signal Range | 0-5 VDC, 0-10 VDC, 1-5 VDC, +/- 5 VDC and +/- 10 VDC | |
| External Power Requirement | 24 VDC | |
| Programming Software | DirectSOFT programming software v4.0 or later | |
