| Technical Data | ||
|---|---|---|
| Brand | IronHorse | |
| Item | Combo module | |
| I/O Module Type | Relay/analog | |
| Series | GSD8 | |
| Number of Analog Input Channels | 1 | |
| Analog Input Signal Type | Current | |
| Analog Input Type | Sinking | |
| Number of Isolated Analog Input Commons | 1 | |
| Number of Points per Analog Input Common | 1 | |
| Input Current Signal Range | 4-20 mA | |
| Number of Analog Output Channels | 1 | |
| Analog Output Signal Type | Current | |
| Number of Isolated Analog Output Commons | 1 | |
| Number of Points per Analog Output Common | 1 | |
| Output Current Signal Range | 4-20 mA | |
| Number of Discrete Output Points | 1 | |
| Nominal Output Voltage | 50 VAC | |
| Discrete Output Type | Relay | |
| Relay Configuration | (1) Form C (SPDT) relay | |
| Number of Isolated Discrete Output Commons | 1 | |
| Number of Points per Discrete Output Common | 1 | |
| Load Current | 1A/point | |
| For Use With | Multiple GSD8 series DC drives | |
