| Technical Data | ||
|---|---|---|
| Brand | IronHorse | |
| Item | Gearbox | |
| Application | General purpose | |
| Duty Rating | Heavy-duty | |
| Gearbox Type | Helical | |
| Gear Ratio | 40:1 | |
| Speed Rating | 1750rpm input / 44rpm output | |
| Input Configuration | 56C-Face | |
| Input Power Rating | Nominal 1hp at 1.0 SF | |
| Output Configuration | Inline | |
| Gearbox Output Shaft Diameter | 1in | |
| Mechanical Output Torque | 1310 lb-in | |
| Thermal Output Torque | 1310 lb-in | |
| Frame | Type-37 | |
| Housing Material | Cast iron | |
| Mounting | Foot | |
| Finish | Anti-corrosion primer and paint | |
| Lubrication Type | Pre-filled with HD320 mineral oil | |
| Oil Seal Type | Double-lip | |
| Includes | Motor mounting hardware | |
