| Technical Data | ||
|---|---|---|
| Brand | International Power | |
| Item | Power supply | |
| Power Supply Type | Regulated linear | |
| Efficiency | 45% @ 120 VAC | |
| Output Configuration | Triple output | |
| Output | 5 VDC @ 2A/10W | |
| Output 2 | 12 or 15 VDC @ 0.4A/6W | |
| Output 3 | -5, -12 or -15 VDC @ 0.4A/6W | |
| Input voltage range | 120/240 VAC | |
| Input Voltage Selection Type | Jumper | |
| Number of Input Phases | 1 | |
| Protection Type(s) |
| |
| Remote On/Off | No | |
| Voltage Monitoring | No | |
| Enclosure Type | Open frame | |
| Housing Material | Aluminum | |
| Mounting | Chassis | |
| Connector Type | Turret terminals | |
| NEC Class 2 | No | |
| Integrated UPS Battery Control | No | |
| Operating Temperature | 0 to 50 deg C | |
