IM3-8-BD-16-1-4-N-B

IM3-8-BD-16-1-4-N-B

CITO Inline air, coolant, oil or water manifold, anodized aluminum, blue, rectangular, 3000 psi maximum operating pressure, (8) stations, (2) 3/4in female NPT inlet(s), (16) 1/4in female NPT outlet(s), 45-deg and 135-deg orientation.

$165
/
Technical Data
BrandCITO
ItemManifold
SeriesInline
Working FluidPneumatic, coolant, oil or water
MaterialAnodized aluminum
ColorBlue
ShapeRectangular
Body Length8.75in
Number of Stations8
Maximum Operating Pressure3000 psi
Inlet Port(2) 3/4in female NPT
Outlet Port(16) 1/4in female NPT
Hole Orientation45-deg and 135-deg
IncludesIM-3030 end cap and mounting screws
