| Technical Data | ||
|---|---|---|
| Brand | IDEM | |
| Item | Safety switch | |
| Actuator Type | Tongue (key) interlock | |
| Lock Type | Solenoid, 24 VAC/VDC to unlock | |
| Head Type | 90-degree adjustable | |
| Holding Force | 2000N | |
| Safety Output Type | (4) N.C. | |
| Monitoring Output Type | (1) N.O. | |
| Additional Contacts | (1) selectable output (N.O. auxiliary or LED) for lock status | |
| Indicating Type | (1) solenoid status LED, (1) selectable lock status LED | |
| Housing Size | 46 x 176 x 46mm | |
| Body Material | Die-cast aluminum | |
| Head Material | Die-cast aluminum | |
| IP Rating | IP67 | |
| Connection | (3) 1/2in NPT cable entries | |
| Includes | (1) tamper-proof T20 Torx bit | |
