| Technical Data | ||
|---|---|---|
| Brand | IronHorse | |
| Item | Motor | |
| Series | MTR | |
| Efficiency Group | Premium efficiency | |
| Efficiency | 77 | |
| Voltage Type | AC | |
| Motor Type | Induction | |
| Motor Application | Centrifugal jet pump | |
| Horsepower Rating | 1hp | |
| Number of Phases | 3 | |
| Voltage Rating | 208-230/460 VAC | |
| Synchronous Speed | 3600rpm | |
| Nameplate RPM | 3500rpm | |
| Overload Type | None | |
| Enclosure Type | TEFC | |
| Shaft Type | Round threaded 20 UNF-2A | |
| Shaft Diameter | 5/8in | |
| Shaft Material | AISI 420 stainless steel | |
| Motor Frame | NEMA 56J | |
| Frame Material | Rolled steel | |
| Electrically Reversible | Yes | |
| Insulation Class | Class F | |
| IP Rating | IP43 | |
| Service Factor | 1.15 | |
| Integrated Brake | No | |
| NEMA Design | Design B | |
| Junction Box Orientation | F1 | |
| Mounting | C-face/removable rigid base | |
| Mounting Orientation | Horizontal or vertical | |
