| Technical Data | ||
|---|---|---|
| Brand | Atlas Wire | |
| Item | Wire | |
| Wire/Cable Type | MTW | |
| UL Wire/Cable Type | AWM and MTW | |
| Applicable Standards | UL 758, UL 1015, UL 1230, UL 1032, CSA C22.2 No. 210, UL 1011, UL 1013 and UL 1335 | |
| Application | Hook-up | |
| Flexibility | Flexible | |
| Voltage Rating | 600V | |
| Conductors | Single conductor | |
| Conductor Size | 22 AWG | |
| Conductor Stranding | 7-stranded | |
| Conductor Material | Bare copper | |
| Conductor Insulation Material | PVC | |
| Conductor Insulation Color | Green with yellow stripe | |
| Nominal Overall Cable Diameter | 0.092in | |
| Bulk Length | 500ft spool | |
