| Technical Data | ||
|---|---|---|
| Brand | Productivity1000 | |
| Item | Combo module | |
| I/O Module Type | Analog | |
| Number of Input Channels | 4 | |
| Input Signal Type(s) | Current | |
| Analog Input Type | Sinking | |
| Number of Non-Isolated Input Commons | 1 | |
| Input Resolution | 13-bit | |
| Input Current Signal Range | 0-20 mA | |
| Number of Output Channels | 2 | |
| Output Signal Type | Current | |
| Analog Output Type | Sourcing | |
| Number of Non-Isolated Output Commons | 1 | |
| Output Resolution | 12-bit | |
| Output Current Signal Range | 4-20 mA | |
| External Power Requirement | 24 VDC | |
| Requires | P1-10RTB or P1-10RTB-1 removable terminal block or ZIPLink pre-wired cables | |
| Programming Software | Productivity Suite programming software v3.3 or later | |
| Additional Information | Optional ZIPLink connector modules and pre-wired cables are available | |
