| Technical Data | ||
|---|---|---|
| Brand | Metrol | |
| Item | Limit switch | |
| Application | Tool setter | |
| Switch Type | High precision touch | |
| Housing Size | 23 x 38 x 18mm | |
| Head Type | 5mm flat | |
| Actuator Type | 16mm plunger | |
| Contact Force | 1.5N | |
| Contact Type | (1) N.C. | |
| Cable Length | 9.8ft/3m | |
| Connection | Pigtail | |
| Conductor Size | 19 AWG | |
| Stroke | 3mm | |
| Repeatability | 0.0005mm | |
| Material | Stainless steel | |
| Head Material | Tungsten carbide | |
| IP Rating | IP67 | |
| Operating Temperature | 0 to 80 deg C | |
| Indicating Type | LED indication | |
| Mounting | Upward | |
| Mounting Hole Spacing | 10mm | |
