| Technical Data | ||
|---|---|---|
| Brand | SureGear | |
| Item | Gearbox | |
| Application | Precision | |
| Gearbox Type | Planetary | |
| Gear Ratio | 10:1 | |
| Output Configuration | Inline | |
| Gearbox Output Shaft Diameter | 0.5in | |
| Nominal Output Torque | Nominal output torque 16 N-m (142 lb-in) | |
| Number of Stages | 1 | |
| Frame | NEMA 34 | |
| For Use With | SureStep NEMA 34 motors | |
| Includes | Input adapter bushing for 1/2in motor shaft, motor mounting hardware and output shaft key | |
