| Technical Data | ||
|---|---|---|
| Brand | RHINO | |
| Item | Power supply | |
| Series | PSE | |
| Power Supply Type | Switching | |
| Efficiency | 81% @ 115 VAC, 82% @ 230 VAC | |
| Output Configuration | Single output | |
| Output | 12 VDC @ 5A/60W | |
| Output Voltage Range | 12 VDC | |
| Input voltage range | 85-264 VAC (47-63 Hz) | |
| Number of Input Phases | 1 | |
| Protection Type(s) |
| |
| Remote On/Off | No | |
| Voltage Monitoring | Yes | |
| Enclosure Type | Encapsulated | |
| Housing Material | Plastic resin and fiberglass | |
| Mounting | Chassis | |
| Connector Type | Screw terminals | |
| NEC Class 2 | No | |
| Integrated UPS Battery Control | No | |
| Operating Temperature | -10 to 50 deg C | |
