| Technical Data | ||
|---|---|---|
| Brand | RHINO | |
| Item | Redundancy module | |
| Number of Inputs | 2 | |
| Nominal Input Voltage | 24 VDC | |
| Input voltage range | 24-28 VDC | |
| Nominal Output Voltage | 24 VDC | |
| Output Voltage Range | 24-27 VDC | |
| Amperage Rating | 15A | |
| Alarm Contact for Operation Monitoring | Yes | |
| Active Current Sharing | Yes | |
| Housing Material | Metal | |
| Mounting | 35mm DIN rail | |
| Connector Type | Removable screw terminals | |
| Requires | (2) PSM24 power supplies | |
