| Technical Data | ||
|---|---|---|
| Brand | RHINO | |
| Item | Redundancy module | |
| Number of Inputs | 2 | |
| Nominal Input Voltage | 5/12/24 VDC | |
| Input voltage range | 5-60 VDC | |
| Nominal Output Voltage | 5/12/24 VDC | |
| Output Voltage Range | 4-59 VDC | |
| Amperage Rating | 8A | |
| Alarm Contact for Operation Monitoring | No | |
| Active Current Sharing | No | |
| Housing Material | Plastic | |
| Mounting | 35mm DIN rail or chassis | |
| Connector Type | Removable screw terminals | |
| Requires | (2) matched 24 VDC power supplies | |
