| Technical Data | ||
|---|---|---|
| Brand | RHINO TOUGH | |
| Item | Power supply | |
| Series | PSRT | |
| Power Supply Type | Switching | |
| Efficiency | 91.4% @ 115 VAC, 92.1% @ 230 VAC | |
| Output Configuration | Single output | |
| Output | 24 VDC @ 3.8A/91.2W | |
| Output Voltage Range | 24 VDC | |
| Input voltage range | 90-265 VAC/90-240 VDC | |
| Input Voltage Selection Type | Automatic | |
| Number of Input Phases | 1 | |
| Protection Type(s) |
| |
| Remote On/Off | No | |
| Voltage Monitoring | Yes | |
| Enclosure Type | Encapsulated | |
| Housing Material | Aluminum | |
| IP Rating | IP67 | |
| Mounting | Chassis | |
| Connector Type | (1) 7/8in - 16 UN2 4-pin female and (1) 7/8in - 16 UN2 3-pin male | |
| NEC Class 2 | Yes | |
| Integrated UPS Battery Control | No | |
| Operating Temperature | -40 to +85 deg C | |
| Power Boost | 150% for 4s | |
