| Technical Data | ||
|---|---|---|
| Brand | GC Valves | |
| Item | Valve | |
| Working Fluid | Pneumatic, inert gas, water, coolant or light oil | |
| Valve Type | Solenoid process | |
| Port Quantity | 2-port (2-way) | |
| Number Of Positions | 2 | |
| Valve Configuration | N.C. | |
| Action | Single solenoid spring return | |
| Body Material | Brass | |
| Seal Material | Viton | |
| Inlet Port | 3/4in female NPT | |
| Outlet Port | 3/4in female NPT | |
| Flow Coefficient | 6.7 | |
| Maximum Operating Pressure | Varies with fluid | |
| Minimum Operating Pressure | 0 psi | |
| Working Fluid Temperature | 230 deg F maximum | |
| Operating Voltage | 120 VAC | |
| Power Rating | 10 VA | |
| Electrical Connection | 18mm DIN style wiring plug | |
