SC912YN16VFBA4

SC912YN16VFBA4

CFA solenoid valve, 2-port (2-way), 2-position, N.O., stainless steel body, Viton seal(s), 1/4in female NPT inlet(s), 1/4in female NPT outlet(s), Cv=0.065, 0 psi minimum operating pressure, 24 VDC operating voltage, 11mm DIN style wiring plug.

$90
/
Technical Data
BrandCFA
ItemValve
Working FluidPneumatic, inert gas, water or coolant
Valve TypeSolenoid process
Port Quantity2-port (2-way)
Number Of Positions2
Valve ConfigurationN.O.
ActionSingle solenoid spring return
Body MaterialStainless steel
Seal MaterialViton
Inlet Port1/4in female NPT
Outlet Port1/4in female NPT
Flow Coefficient0.065
Maximum Operating Pressure95 psi
Minimum Operating Pressure0 psi
Working Fluid Temperature230 deg F maximum
Operating Voltage24 VDC
Power Rating4W
Electrical Connection11mm DIN style wiring plug
Downloads
Technical Specifications Manual Insert Software Firmware Helpfile 2d Drawing 3d Model
