| Technical Data | ||
|---|---|---|
| Brand | Sung-Il Machinery | |
| Item | Drive coupling | |
| Coupling Type | Servo high gain | |
| Material | Aluminum alloy | |
| Rated Torque | 3.5 N-m | |
| Maximum Torque | 7 N-m | |
| Maximum Angular Misalignment | 1.5 degrees | |
| Maximum Parallel Misalignment | 0.15mm | |
| Maximum RPM | 25000 | |
| Attachment Style | Clamp | |
| Coupling Size | 24 | |
| Overall Length | 31.2mm | |
| Bore Diameter | 8mm | |
| Bore Diameter 2 | 10mm | |
| Outside Diameter | 23.8mm | |
| Clamp Screw Fastening Torque | 1.1 N-m | |
| Clamp Screw Size | M2.6-0.45 x 8mm | |
