| Technical Data | ||
|---|---|---|
| Brand | STRIDE | |
| Item | Combo module | |
| I/O Module Type | Discrete | |
| Number of Input Points | 8 | |
| Nominal Input Voltage | 12-24 VDC | |
| Discrete Input Type | Sinking | |
| Number of Non-Isolated Discrete Input Commons | 1 | |
| Number of Points per Discrete Input Common | 8 | |
| Number of Output Points | 8 | |
| Nominal Output Voltage | 12-24 VDC | |
| Discrete Output Type | Sourcing | |
| Number of Non-Isolated Discrete Output Commons | 1 | |
| Number of Points per Discrete Output Common | 8 | |
| Load Current | 0.5A/point, 1A/module | |
| Communication Port and Connection Type(s) |
| |
| Port Protocol(s) |
| |
| Port Speed(s) |
| |
| External Power Requirement | 10-30 VDC | |
| Programming Software | None, configure via Internet browser | |
