| Technical Data | ||
|---|---|---|
| Brand | Sung-Il Machinery | |
| Item | Drive coupling hub | |
| Coupling Type | Oldham | |
| Material | Aluminum alloy | |
| Rated Torque | 7 N-m | |
| Maximum Torque | 14 N-m | |
| Slip Torque | 8 N-m | |
| Maximum Angular Misalignment | 1.5 degrees | |
| Maximum Parallel Misalignment | 2.5mm | |
| Maximum RPM | 9000 | |
| Attachment Style | Clamp | |
| Coupling Size | 32 | |
| Overall Length | 44.7mm | |
| Bore Diameter | 8mm | |
| Outside Diameter | 32mm | |
| Clamp Screw Fastening Torque | 3.5 N-m | |
| Clamp Screw Size | M4-0.7 x 12mm | |
| Requires | SOH-32-DISC torque disc | |
