ST7P-2A13T-ADC

ST7P-2A13T-ADC

Fuji Electric on-delay relay timer, 2 to 30 seconds selectable timing range, 100-120 VAC operating voltage, 3A contact rating, (1) DPDT timed relay output(s), socket mount, 8-pin. Requires Fuji Electric TP88X2 timer socket.

$68.75
/
Technical Data
BrandFuji Electric
ItemRelay timer
Timer TypeOn-delay
IndicatorLED
Timing Range2 to 30 seconds selectable
Operating Voltage100-120 VAC
Timer Output Type(s)(1) DPDT timed relay
Output Type(2) N.O., (2) N.C.
Timer Function(s)
  • on-delay
Contact Rating3A
MountingSocket
Connector Type8-pin
RequiresFuji Electric TP88X2 timer socket
Downloads
Technical Specifications Manual Insert Software Firmware Helpfile 2d Drawing 3d Model
