| Technical Data | ||
|---|---|---|
| Brand | CITO | |
| Item | Valve | |
| Working Fluid | Coolant, oil or water | |
| Valve Type | Solenoid process | |
| Series | StackValve | |
| Port Quantity | 2-way | |
| Number Of Positions | 2 | |
| Valve Configuration | N.C. | |
| Action | Single solenoid spring return | |
| Body Material | Glass-filled nylon | |
| Stackable | Yes | |
| Flow Coefficient | 8.5 | |
| Maximum Operating Pressure | 100 psi | |
| Minimum Operating Pressure | 5 psi | |
| Working Fluid Temperature | 20 to 160 deg F | |
| Operating Voltage | 24 VAC/VDC | |
| Power Rating | 7.2W | |
| Electrical Connection | 18mm DIN style wiring plug | |
| Indicating Type | LED indication | |
| Form Factor | Modular | |
| Includes | RA-3903 high-flow turbine and SF-9130 screen | |
