| Technical Data | ||
|---|---|---|
| Brand | Fandis | |
| Series | Virdis series | |
| Airflow Direction | Exhaust | |
| Item | Fan | |
| Mounting | Top | |
| With Air Flaps | No | |
| Filter Media | G2 (coarse) filter mat | |
| Free Airflow | 288 CFM | |
| Airflow with Grill and Filter(s) | 259 CFM | |
| Operating Voltage | 115 VAC | |
| Frequency | 60 Hz | |
| Power Consumption | 97W | |
| Current Draw | 850 mA | |
| Electrical Connection | Terminal block | |
| Maximum Static Pressure | 480Pa | |
| Operating Temperature | 14 to 131 deg F | |
| Average Noise Level | 72 dBA | |
| NEMA Rating | 12 | |
| Application | Indoor use only | |
| IP Rating | IP54 | |
| Enclosure Cutout | 6.89 x 6.89in | |
| Color | RAL 7035 light gray | |
| Includes | Mounting screws | |
| Additional Information | Purchase intake grille separately. Fan will also safely operate at 50Hz, but with reduced airflow. Refer to technical specifications for 50Hz performance data | |
