| Technical Data | ||
|---|---|---|
| Brand | JTEKT | |
| Item | Encoder | |
| Series | TRD-SR | |
| Feedback Type | Incremental (quadrature) | |
| Encoder Type | Rotary | |
| Voltage Rating | 5 VDC | |
| Encoder Output Type | Line driver (differential) | |
| Duty Rating | Light duty | |
| Programmable Encoder Resolution | No | |
| Encoder Resolution | 200 ppr | |
| Shaft Type | Hollow | |
| Shaft Diameter | 8mm | |
| Radial Shaft Load | 30N | |
| Axial Shaft Load | 20N | |
| Frequency Response | 200 kHz | |
| Speed Rating | 6000rpm | |
| Flange Mount | No | |
| Encoder Body Diameter | 38mm | |
| Housing Material | Aluminum | |
| IP Rating | IP50 | |
| Cable Length | 6.5ft/2m | |
| Cable Diameter Size | 6mm | |
| Wire Size | 26 AWG | |
| Exit Orientation | Radial | |
| Connector Type | Pigtail | |
