| Technical Data | ||
|---|---|---|
| Brand | IDEM | |
| Series | UGB-NET | |
| Item | Gate box | |
| Gate Box Type | Networked | |
| Actuator Type | Tongue (key) interlock uniquely coded RFID | |
| Switch Configuration | 4 station | |
| Door Type | Left hand | |
| Lock Type | Solenoid, 24 VDC to unlock | |
| Rear Release | No | |
| Head Type | 90-degree fixed | |
| Holding Force | 3000N | |
| Port Protocol(s) | CIP-Safety | |
| Indicating Type | (6) status LEDs | |
| Housing Size | 115 x 230 x 62mm | |
| Body Material | Die-cast aluminum | |
| Head Material | 316 stainless steel | |
| IP Rating | IP65 | |
| Connection | (2) 4-pin M12 female D-coded, (1) 5-pin M12 male A-coded and (1) 5-pin M12 female A-coded | |
| Includes | (1) illuminated Estop, (3) illuminated push buttons, and lens pack | |
