| Technical Data | ||
|---|---|---|
| Brand | Gefran | |
| Item | Linear position sensor | |
| Transducer Type | Magnetostrictive | |
| Action | Rodless slide | |
| Stroke | 400mm | |
| Output | 4-20 mA | |
| Housing Material | Anodized aluminum | |
| Housing Size | 33 x 16.3 x 554mm | |
| Operating Voltage | 19.2-28.8 VDC | |
| Sensor Resolution | Infinite | |
| Linearity | +/- 0.04% | |
| Mounting | Channel | |
| IP Rating | IP67 | |
| Connection | 18mm DIN 43650 Form A | |
| Number of Wires | 4 | |
| Additional Information | Purchase cursor and mounting brackets separately | |
